15 Inch SAW Touch Monitor Open Frame IP65 Surface Waterproof
SAW Touch Monitor Main Features:
-
KeeTouch SAW touch panel, high sensitivity and good touch experience
-
High resolution SAW touch Monitor with high-quality image
-
Anti-glare, vandal-proof and IP65 front frame waterproof SAW touch monitor
-
VGA & DVI interfaces,USB for touch
-
Multiple mounting options include VESA mount, horizontal and vertical brackets mount
-
Other sizes can be offered (7’’- 43’’)
SAW Touch Monitor Specifications
| Complete Machine |
| Model No. | KOT-0150US-SA6BCW (P/N:KOT-150C-003) |
| Series | OT,waterproof |
| Display Type | 4:3 Ratio 15" TFT-LCD |
| Active Area | 304.1*228.1(mm) |
| Monitor Dimensions (W*H*D) | 336.4*264.4*45.9(mm) |
| Suggested Resolution | 1024*768 @ 60Hz |
| Support Colors | 16.2M |
| Brightness (Typ.) | Pure LCD Panel | 420cd/m2 |
| | With Touch Monitor | 378cd/m2 |
| Response Time (Typ.) | 5ms |
| Viewing Angle(Typ.at CR＞10)) | Horizontal(left/right) | 80°/80° |
| Vertical(up/down) | 80°/80° |
| Contrast Ratio (Typ.) | 800:1 |
| Video Input | VGA/DVI |
| Frequency (H/V) | 30～60KHz / 60～75Hz |
| Power Supply | Type: External brick Display voltage: DC 12V±5% Input (line) voltage: 100-240 VAC, 50-60 Hz |
| Environment | Operating Temp. | 0～50°C |
| Operating RH | 20%～80% |
| Storage Temp. | -20～60°C |
| Storage RH | 10%～90% |
| MTBF | 50,000 Hours |
| LED Back Light Life (Typ.) | 50,000 Hours |
| Weight(N.W/G.W) | 3.5Kg(1pcs)/11Kg(2pcs in one package) |
| Package dimensions | 429*183*356(mm)(2pcs in one package) |
| Power Consumption | Standby Power: ≤1.5W / Operating Power: ≤12W |
| Mount Interface | 1.VESA 75mm and 100mm 2.Mount bracket, horizontal or vertical mount |
| OSD Control | Buttons | AUTO,+,POWER,-,MENU |
| Function | Brightness, Contrast Ratio, Auto-adjust, Phase, Clock, H/V Location, Languages, Function, Reset |
| Touch Screen Type | KeeTouch 15" SAW 6 mm Compact Touchscreen(anti-glare,vandal-proof) |
| Touch System Interface | Having USB and Serial(RS232) Interface |
| Touch Response Time | USB/Serial: 8.4/10.4ms |
| Agency approvals | CCC, UL, FCC, CE, CB, RoHS |
| Regular Warranty | 1 year |
SAW Touch Monitor Mechanical Dimensions
Applications
KeeTouch products are widely used in industries such as retail, gaming, kiosk, self-service, finance, transit, conference, education, healthcare, public service, e-commerce, hotels, restaurants, travel service, payment systems, museums, exhibitions, smart home, subways, railway stations, control and operation systems, airports, entertainments, etc.
FAQ
1. Are you a manufacturer?
Yes, KeeTouch is a professional touch product manufacturer for over 16 years, located in Shenzhen, China.
2. What’s your MOQ for the SAW Touch Monitor?
Our minimum order quantity is 1pc only.
3. What is your warranty period for the SAW Touch Monitor?
Our regular warranty is 12 months for all the products, with 2-3 years Warranty (optional).
4. Can you produce the SAW Touch Monitor according to the customer's requirements?
Sure, with 40+ Professional R & D engineers, OEM and ODM are welcomed.
